TBTL CTF 2024 - Your papers, please

Moving all of my past CTF write-ups to this website…

My flight got delayed, and I had to rebook to one that leaves 7 hours later. That leaves me free to do another write-up!

This was a simple one, but the number of solves was surprisingly few.

Note from myself 9mo later: This actually came up in another CTF recently and had few solves. It’s honestly comes across as a very real bug that could happen, so I definitely recommend keeping this challenge in the back of your mind!

Of course, there were some I couldn’t solve that had a good amount of solves, so I’m not judging.

Also a quick note that I tagged it ctf:web because I don’t recall the original category, and, using JWTs, it might as well be web.

Challenge

the challenge mainly featuring a link to the python code and a link to a JWT

Here, we’re given the address to a server, the server’s code, a list of required python packages, and a JWT 🔗.

Here’s the server code:

#!/usr/bin/python3

import base64
import datetime
import json
import os
import signal

import humanize
import jwt


# openssl ecparam -name secp521r1 -genkey -noout -out private.key
# openssl ec -in private.key -pubout -out public.pem
PUBLIC_KEY = u'''-----BEGIN PUBLIC KEY-----
MIGbMBAGByqGSM49AgEGBSuBBAAjA4GGAAQBGOtycGkAMpTEDsjFykEywLecIdCX
1QIShxmJB0qJj9K2yFNwJj/eRR6yzIZcHJPZWzQU6Mad62y1MsJ8uOgdZ2sBmkS0
HJtT4FZq/EQbtkHeahsDnSLbFpPfoN/t8hmKrVmDzDRGe3PNl7OQVuzoY2TVSxVK
IKmpZ9Pw9/5HOzSmOxs=-----END PUBLIC KEY-----
'''


def myprint(s):
    print(s, flush=True)


def handler(_signum, _frame):
    myprint("Time out!")
    exit(0)


def decode(token):
    signing_input, crypto_segment = token.rsplit(".", 1)
    header_segment, payload_segment = signing_input.split(".", 1)
    header_data = base64.urlsafe_b64decode(header_segment)
    header = json.loads(header_data)
    alg = header["alg"]
    return jwt.decode(token, algorithms=[alg], key=PUBLIC_KEY)


def main():
    signal.signal(signal.SIGALRM, handler)
    signal.alarm(300)

    myprint("Your papers, please.")
    token = input()
    try:
        mdl = decode(token)
        assert mdl["docType"] == "iso.org.18013.5.1.mDL"
        family_name = mdl["family_name"]
        given_name = mdl["given_name"]
        expiry_date = datetime.datetime.strptime(mdl["expiry_date"], "%Y-%m-%dT%H:%M:%S.%f")
    except Exception as e:
        myprint("Your papers are not in order!")
        exit(0)
    myprint("Hello {} {}!".format(given_name, family_name))
    delta = expiry_date - datetime.datetime.now()
    if delta <= datetime.timedelta(0):
        myprint("Your papers expired {} ago!".format(humanize.naturaldelta(delta)))
        exit(0)

    flag = open("flag.txt", "r").read().strip()
    myprint("Your papers are in order, here is your flag: {}".format(flag))
    exit(0)


if __name__ == '__main__':
    main()

In essence, we need to give it a JWT that can be decoded with PUBLIC_KEY and is not expired. Here’s the JWT we’re given:

eyJhbGciOiJFUzUxMiIsInR5cCI6IkpXVCJ9.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.ATOuXnzmtdiOPhuu1ksgF6FqKjHNHJoyMLHF28xsRgVNUANFlUv9l_xM9TGg_s9ZbFy6gimaH80MSHl6wHOxg8yxAFS22jy1GEPX3Kc4ZPUKEjd7q6vbo1zLXEfNjpkwBbU6M9pbqS6CmBxM1MY93WDjNY8p5mGYdBtbD3XccmOivGDH

And in decoded form 🔗:

// Header:
{
  "alg": "ES512",
  "typ": "JWT"
}

// Payload
{
  "version": "1.0",
  "docType": "iso.org.18013.5.1.mDL",
  "family_name": "TURNER",
  "given_name": "SUSAN",
  "birth_date": "1998-08-28",
  "issue_date": "2018-01-15T10:00:00.00",
  "expiry_date": "2022-08-27T12:00:00.00",
  "issuing_country": "US",
  "issuing_authority": "CO",
  "document_number": "542426814",
  "driving_privileges": [
    {
      "codes": [
        {
          "code": "D"
        }
      ],
      "vehicle_category_code": "D",
      "issue_date": "2019-01-01",
      "expiry_date": "2027-01-01"
    }
  ],
  "un_distinguishing_sign": "USA"
}

// And signature information that we don't care about.

Analysis

This JWT is expired, so we can’t use it directly. Strictly speaking, we don’t even have to use this JWT as a base, but let’s use it anyway.

Now, until now, I wasn’t familiar with the details of JWTs. The biggest mystery is what ES512 means, so I asked my best friend: Google Search. It actually brought me to a documentation page for the very library used in the server 🔗 and has a description of the various supported algorithms. ES512 refers to ECDSA signature algorithm using SHA-512 hash algorithm. This means it uses asymmetric encryption, which I suppose we can guess by the presence of a public key in the server anyway.

After reading this and the code, the solution jumped right out at me! In the decode function:

def decode(token):
    signing_input, crypto_segment = token.rsplit(".", 1)
    header_segment, payload_segment = signing_input.split(".", 1)
    header_data = base64.urlsafe_b64decode(header_segment)
    header = json.loads(header_data)
    alg = header["alg"]
    return jwt.decode(token, algorithms=[alg], key=PUBLIC_KEY)

The algorithm is read from the header of the JWT and used to decode it. Double checking the API 🔗…

jwt.decode(jwt, key="", algorithms=None, options=None, audience=None, issuer=None, leeway=0)

Exploit

It appears that, regardless of whether symmetric or asymmetric encryption is used,both use the key parameter. The solution is therefore to encode our non-expired JWT using symmetric key encryption, where the key is the public key that would normally be used in asymmetric encryption. This can all be done one from the JWT debugger page 🔗 linked above.

screenshot of pasting our new JWT and receiving the flag
TBTL{1n_H34d3rS_W3_Tru$7}

The important moral of the story, since code seems innocuous at first glance: ignore/whitelist the the alg header and use only the appropriate key for the appropriate algorithm.

And, more importantly, for those designing a JWT API…

jwt.decode(jwt, key="", algorithms=None, options=None, audience=None, issuer=None, leeway=0)

This isn’t really the way to go about it. Instead, accept algorithm and key as a tuple. It also conveniently solvesa key rotation issues if multiple keys are accepted anyway.

# or, instead of or in addition to tuples, and object/dict is probably better
jwt.decode(token, keys=[("ES512", PUBLIC_KEY)])
